| VESSEL NAME | REF747 |
| FLAG | BAHAMAS |
| PORT OF REGISTRY | NASSAU |
| BUILT YEAR | 1990 |
| BUILT PLACE | GEBR. VAN DIEPEN, NETHERLANDS |
| CLASSIFICATION | BV |
| CLASS NOTATION | I, +HULL, +MACH, +AUT-UMS, +SYS-NEQ-1, MON-SHAFT, +REF-CARGO, REFRIGERATED CARGO SHIP, UNRESTRICTED NAVIGATION |
| LOA (M) | 135.70 |
| BEAM (M) | 16.29 |
| DEPTH (M) | 9.30 |
| SUMMER DRAFT (M) | 7.63 |
| GT (MT) | 5103.00 |
| NT (MT) | 3338.00 |
| PANAMA NT (MT) | 4381.00 |
| SUEZ NT (MT) | 4329.74 |
| SUMMER DWT (MT) | 6111.00 |
| GEAR(S) | CRANES, 4 x 7.0MT OR 2 x 2.0MT IN UP |
| M/E(S) | MAK 6M601AK, 8973BHP 425RPM |
| M/E POWER (KW) | 6696 |
| SHAFT GENERATOR(S) | YES |
| SPEED/CONSUMPTIONS | FROZEN LADEN: 17KTS ON 24MT +SHAFTGEN BALLAST: 17.5KTS ON 22MT |
| FUEL TYPE | IFO380 |
| BUNKER CAPACITY (CBM) | 705 |
| TANKS CAPACITY (CBM) | MGO: 101 |
| NUMBER OF CARGO HOLDS | 4 |
| HATCH NUMBER | 4 |
| COMPARTMENT(S) | 15 |
| DECK HEIGHT (M) | ≥2.20 |
| CARGO CAPACITY (CBFT) | 310395 |
| CARGO CAPACITY (CBM) | 8793 |
| FLOOR SPACE CAPACITY (SQM) | 3702 |
| GRATING/DECK STRENGTH | MAX 5MT (FORKLIFT TO BE EQUIPED WITH MIN 4 AIRTYRES) |
| TEMPERATURE ZONE(S) | 8 1A/BC, 2AB/CD, 3AB/CD, 4AB/CD |
| TEMPERATURE (℃) | -25 /+12 |
| VENT (TIMES/HOUR) | 90 |
| AIR CHANGE (TIMES/HOUR) | 3 |
| REEFER PLUG(S) | 20 |
