YC6C series marine engine is an ideal main engine power for 35~50meter marine fishing boat,passenger ships with tonnage of 3000~5000ton.ZY,ZC,CCS certificate and IMO certificate are available.This series of marine engine can be serves as marine propulsion and auxiliary engine for vessels.
Main Engine Datas:
1.Types:Vertical,In-line,water cooled,4stroke
2.Intake way:Turbo-charging and inter-cooling
3.CylinderBoreStroke:6-200210
4.Displacement:39.58
5.Compression ratio:14.5:1
6.Dimension(LWH):276012851940
YC6CSeries Diesel Engine Technical Parameters:
|
Engine Model |
Rate Power/Speed (kw/r/min) |
Overload power/speed (kw/r/min) |
Remark |
|
YC6C460L-C20 |
339/1000 |
372.9/1032 |
Propulsion(finishing boat) |
|
YC6C480L-C20 |
352/1000 |
387/1032 |
Propulsion(passenger vessels, Cargo ship,fishing boat) |
|
YC6C530L-C20 |
389/1000 |
429/1032 |
Propulsion(finishing boat) |
|
YC6C560L-C20 |
411/1200 |
468.6/1238 |
Propulsion(finishing boat) |
|
YC6C580L-C20 |
426/1200 |
485.1/1238 |
Propulsion(finishing boat) |
|
YC6C600L-C20 |
441/1200 |
533.5/1238 |
Propulsion(finishing boat) |
|
YC6C660-C20 |
485/1200 |
509.3/1393 |
Propulsion(finishing boat) |
|
YC6C630-C20 |
463/1350 |
557.7/1393 |
Propulsion(finishing boat) |
|
YC6C690-C20 |
507/1350 |
567/1032 |
Propulsion(passenger vessels, Cargo ship,fishing boat) |
|
YC6C700L-C20 |
515/1000 |
567/1000 |
Auxiliary engine |
|
............. |
............ |
................ |
................. |
|
More Engines can be offered,pls contact us for more details. |
|||
